LEVTECH - LSP-TSTS-100-420 - Modules - ICDC-036000 - New
Temperature 4-20mA transmitter for Pt100
Lead Time:
Next Day Shipping + DHL Express Transit Time€ 66,00 per piece, VAT excluded
5 in stock
LEVTECH – LSP-TSTS-100-420 – Modules – ICDC-036000 – New
Main Category: Electronics | Sub-Category: Modules | Status: New Original Components
LEVTECH Part Number: LSP-TSTS-100-420 | ICDC Part Number: ICDC-036000
Description:
The LSP-TSTS is a slim design easy to use temperature transmitter for Pt100 3 wire or 2 wire temperature sensor. This device provides a linearised 4-20mA signal output, proportional to the temperature characteristic of the Pt100 sensor. Temperature range can be changed on request before order (Default -15 to 150ºC). This temperature transmitter is designed to provide a linearised 4-20mA signal output, proportional with the temperature characteristic of the Pt100 sensor connected on its input. On the input it is possible to connect both 3 wires and 2 wires Pt100 . The transmitter has to be ordered for the specific sensor type. This transmitter is suitable for any industrial application and with its DIN rail mountable enclosure it is easy to install in electrical cabinets. The transmitter acquires its supply voltage from the current loop and no additional supply is needed. The slim design of this product save place in the electric cabinet.
For different temperature range then the default (-15 to 150ºC), please contact us.
Features
– RTD type Pt100 Input
– 4 to 20 mA linearised output on current loop
– TS-35 DIN rail mounting
– +/-0.1% accuracy
– IP40 case
– Screw terminals
– Easy to use
– Supply from current loop
– Made in EU
