AVENTICS - 0821302447 - Valve
REDUCER 0.1-7 R PILOT 1/4 0821302447
Lead Time:
Next Day Shipping + DHL Express Transit Time€ 94,50 per piece, VAT excluded
1 in stock
AVENTICS by EMERSON – 0821302447 – Valve
Main Category: Pneumatic | Sub-Category: Valve | Status: New Original ComponentsAVENTICS Part Number: 0821302447 | ICDC Part Number: ICDC-000792
Description:
Reducer 0.1-7 R Pilot 1-4 0821302447 – Precision pressure regulator, Series PR1-RGP
| Activation | Mechanical |
| Parts | Precision pressure regulator |
| Relieving exhaust | with relieving air exhaust |
| Housing | Brass |
| Sealing material | Acrylonitrile butadiene rubber |
| suitable for ATEX | |
| Nominal flow Qn | 1.02 Cv |
| Compressed air connection | G 1/4 |
| Parts | Precision pressure regulator |
| Mounting orientation | Any |
| Certificates | suitable for ATEX |
| Working pressure min./max. | 8 … 232 psi |
| Ambient temperature min./max. | 14 … 140 °F |
| Medium temperature min./max. | 14 … 140 °F |
| Medium | Compressed air Neutral gases |
| Regulator type | Diaphragm-type pressure regulator |
| Regulator function | with relieving air exhaust |
| Adjustment range min./max. | See table |
| Pressure supply | single |
| Activation | Mechanical |
| Weight | 1.36 lbs |
| The pressure dew point must be at least 27 °F under ambient and medium temperature and may not exceed 5.4 °F . Relieving exhaust (≤ 10 mbar over set pressure) Mounting: mounting bracket 1821332056 or installation in piping | |
| Recommended pre-filtering | 0.01 µm |
| Material |
|---|
| Housing | Brass |
| Seals | Acrylonitrile butadiene rubber |
| A1 = input A2 = output | |
| A4 = output |
Contact us to discover AVENTICS – 0821302447 – Valve. ICDCSPARES.COM offers new and original components, ready in stock to be shipped via DHL Express!
Check our Pneumatic section to discover more about ICDC catalog: a large selection of industrial spare parts including Fittings, Fluid Dispensers and Gaskets, beyond Valves.
Are you looking for AVENTICS by EMERSON industrial components? ICDC offers online a wide selection of Valves of the most important OEMs like BUCHER HYDRAULICS, BURKERT CONTROMATIC and CALPEDA, beyond AVENTICS.
ICDC, Your Industrial One Stop Shop for Components!
AVENTICS short coding: 821302447
